50x50 Post Glass Railing System with Welded Base & Caps | JIMEI Glass Railing Profile

Introducing the JIMEI ALU 50x50mm post glass railing system—a mature, comprehensive solution engineered for modern architectural spaces. More than just a post, this system integrates structural stability, refined aesthetics, and installation efficiency. Featuring a 3.0mm heavy-duty wall thickness and pre-welded base plates, it is perfectly suited for residential, commercial, and public safety applications, delivering exceptional performance, especially in long-span installations where it effectively eliminates wobbling.

【Key Features & Benefits】

• Superior Structural Strength & Safety

  • 50x50mm Square Posts: Offer a balanced, modern square profile that provides excellent visual proportion and a solid, comfortable grip.

  • 3.0mm Wall Thickness: Exceeding the common 1.2–2.0mm thickness used in standard residential projects, this heavy-duty specification ensures superior bending and impact resistance for long-term durability.

  • 6mm Pre-Welded Base: Factory-welded to the post, this base is more secure and resistant to deformation compared to split bases fixed with screws on-site. It significantly streamlines installation.

  • 16mm Standard Groove: Designed to accommodate 12mm laminated glass (e.g., 6+6) or glass panels up to 12mm thick, ensuring robust and secure glazing.

• Refined Aesthetics & Detailed Design

  • Matching Decorative Caps: Cover the screw holes securing the base to the floor, resulting in a clean, high-end finish while offering dust and moisture protection.

  • Comprehensive Post Options:

    • Single-Side Post: Ideal for wall ends or single-sided glass terminations.

    • Double-Side Post: Suitable for straight runs where glass panels need to be installed on both sides.

    • Dedicated Corner Post: Specifically designed for 90-degree or custom-angle turns, allowing for seamless glass transitions and visual continuity.

  • Matching Square Handrail (Optional): A sleek, coordinating handrail (sold separately) complements the posts for a unified, contemporary look and a comfortable grip.

• Easy Installation

  • With the pre-welded base and included decorative caps, on-site installation is simplified to three steps: Positioning, Drilling, and Screw Fixing—saving labor and time.

【Application Scenarios】

• Indoor Stairs: Stair railings in duplexes, villas, and LOFT apartments, ensuring safety while maintaining a light-filled, open feel.

• Balcony & Corridor Railings: High-rise balconies, landscape balconies, and connecting corridors requiring safety protection with unobstructed views.

• Commercial & Public Spaces: Hotels, office buildings, shopping malls, and exhibition centers that demand high standards of both safety and aesthetics.

【Installation Instructions】

1. Positioning & Marking: Mark the center points for post installation on the floor or substructure according to the design layout.

2. Fixing the Base: Secure the pre-welded base plate to the concrete or steel substructure using expansion bolts (M8 or M10, depending on the base material). Ensure the post is perfectly vertical.

3. Installing Glass: Insert the 12mm (or thinner) glass panel into the 16mm side groove of the post. Place rubber setting blocks or apply structural sealant within the groove for cushioning and secure fixing.

4. Installing Handrail (Optional): Attach the matching square handrail profile across the tops of the posts to connect the system.

5. Attaching Decorative Caps: Finally, snap the decorative caps over the base plates to completely conceal the fixing screws and complete the installation.
